COMMODITIES PARAMETERS：
|
Voltage
|
AC 220V/110v ±10%
|
|
Frequency
|
50/60Hz
|
|
Wire plug
|
GB 3 cores/EN 3 cores/ American
3 cores
|
|
Max Hp
|
2000VA
|
|
Tank Capacity
|
23L
|
|
Class
|
European Class B standard
|
|
Sterilizing temperature
|
134℃/121℃
|
|
Inside Dinebsion
|
Φ249×450mm
|
|
Net weight
|
53kg
|
Technical parameters:
|
Sterilization level
|
European Class B standard
|
|
Sterilizing temperature
|
134℃/121℃
|
|
Special sterilization
|
Kill active HV,HBV,BSE and spore
|
|
Dry procedure
|
Strong vacuum drying,the residual humidity<0.2%
|
|
Display
|
Widescreen LCD
|
|
Test
|
Bowie&Dick Steam penetration test, vacuum test , Helix test
|
|
Safety
|
Safety valve, Doble Pressure lock Automatic check.
|
|
Sterilizing record
|
Optional USB and printer (internal or external) to record the sterilization process
|
|
Water supply system
|
3L distiller water tank,3L waste water tank
|
|
Clean procedure
|
Automatic clean inside pipe and steam generator
|
|
Instrument containers
|
5 levels with 3 Round trays
|
Product details:
| Model |
Power |
Voltage |
Frequency |
Tank Capacity |
Appearance size |
Inside Dimension |
Outside Dimension |
G"W |
| ZJ-MJ05 |
2000W |
AC220V/110V±10% |
50/60Hz±1Hz |
23Litres |
445X640X395mm |
Ø249x450mm |
720×520×500mm |
53kg |
| ZJ-MJ04 |
1800W |
AC220V/110V±10% |
50/60Hz±lHz |
18Litres |
445X550X395mm |
Ø249x355mm |
670×550×500mm |
48kg |
| ZJ-MJ03 |
1800W |
AC220V/110V±10% |
50/60Hz±1Hz |
16Litres |
445X550X395mm |
Ø230x360mm |
740×550×500mm |
47kg |
| ZJ-MJ02 |
1800W |
AC220V/110V±10% |
50/60Hz±lHz |
12Litres |
445X550X395mm |
Ø200x360mm |
670×550×500mm |
46kg |
PRODUCT CHARACTER:
1. Based on the international prEN13060 new Class B, three-stage pulsating vacuum, the vacuum degree can reach -0.9Bar (-0.09Mpa). Suitable for sterilization packaging
2. Adopt imported advanced 16-bit microprocessor, easy to operate. Best for Dentistry, Ophthalmology, Surgery and Laboratories.
3. With B&D test and vacuum test procedures. to test penetration.
4. Jet steam generator to ensure efficient sterilization.
5. The waste water tank is equipped with an alarm system to prevent waste water from entering the sterilization cycle and complete the sterilization.
6. Accurate digital display and advanced self-inspection system ensure that you can obtain working data as you like.
7. Double lock door system, safe operation.
8. Optional built-in mini printer or USB connector to record the disinfection process
